Stock:
Distributor: 108
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 418.30000 | ₹ 418.30 |
| 25 | ₹ 406.73000 | ₹ 10,168.25 |
| 50 | ₹ 386.26000 | ₹ 19,313.00 |
| 100 | ₹ 364.90000 | ₹ 36,490.00 |
| 252 | ₹ 351.55000 | ₹ 88,590.60 |
| 504 | ₹ 341.76000 | ₹ 1,72,247.04 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | CST | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Operational Hz Spectrum | 20kHz ~ 200kHz | |
| Device Type Classification | Non-Invasive (Solid Core) | |
| Ampere Capacity Rating | 25 A | |
| Coil Inductance Value | 55 mH | |
| Volt-Second Product | 2000VµS | |
| Transformer Turn Ratio | - | |
| Current Proportion | 200:1 | |
| Direct Current Resistance | 3.75Ohm Max | |
| Performance Rating Specs | - | |
| Attachment Mounting Style | Through Hole | |
| Package Size Specs | 0.690" L x 0.385" W (17.53mm x 9.78mm) | |
| Maximum Mounted Height | 0.915" (23.24mm) | |
| Lead Termination Type | PC Pin |
Description
Sets the ampere rating to 25 A. Provides a current ratio assessed at 200:1. Provides a DC resistance measurement of 3.75Ohm Max for accurate circuit operation. Includes ET volt-time rating quantified at 2000VµS. Offers a 20kHz ~ 200kHz frequency spectrum for broad-spectrum applications. Maximum installed height of 0.915" (23.24mm) for components affixed to the board. Provides 55 mH inductance for circuit tuning and filtering. Mounting configuration Through Hole for structural stability. Type of housing Bulk for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Classification series for the product or component CST. Details on package size 0.690" L x 0.385" W (17.53mm x 9.78mm) for electrical or mechanical components. Measurement dimensions 0.690" L x 0.385" W (17.53mm x 9.78mm) for component specifications. Type of termination PC Pin for connector or device. Type classification Non-Invasive (Solid Core) for specifications.
