Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | Omega 30 | |
| IC Encapsulation Type | Retail Package | |
| Availability Status | Active | |
| Operational Hz Spectrum | 50Hz ~ 400Hz | |
| Device Type Classification | Non-Invasive (Solid Core) | |
| Ampere Capacity Rating | 600 A | |
| Coil Inductance Value | - | |
| Volt-Second Product | - | |
| Transformer Turn Ratio | 600:5 | |
| Current Proportion | 120:1 | |
| Direct Current Resistance | - | |
| Performance Rating Specs | - | |
| Attachment Mounting Style | Panel Mount | |
| Package Size Specs | 6.170" L x 6.000" W (156.71mm x 152.40mm) | |
| Maximum Mounted Height | 1.150" (29.21mm) | |
| Lead Termination Type | Stud |
Description
Sets the ampere rating to 600 A. Provides a current ratio assessed at 120:1. Offers a 50Hz ~ 400Hz frequency spectrum for broad-spectrum applications. Maximum installed height of 1.150" (29.21mm) for components affixed to the board. Mounting configuration Panel Mount for structural stability. Type of housing Retail Package for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Classification series for the product or component Omega 30. Details on package size 6.170" L x 6.000" W (156.71mm x 152.40mm) for electrical or mechanical components. Measurement dimensions 6.170" L x 6.000" W (156.71mm x 152.40mm) for component specifications. Type of termination Stud for connector or device. Turns ratio from primary to secondary 600:5 in transformers. Type classification Non-Invasive (Solid Core) for specifications.
