Stock:
Distributor: 110
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 250 | ₹ 4,595.96000 | ₹ 11,48,990.00 |
| 100 | ₹ 4,765.06000 | ₹ 4,76,506.00 |
| 50 | ₹ 4,837.15000 | ₹ 2,41,857.50 |
| 25 | ₹ 4,911.02000 | ₹ 1,22,775.50 |
| 10 | ₹ 5,350.68000 | ₹ 53,506.80 |
| 5 | ₹ 5,515.33000 | ₹ 27,576.65 |
| 1 | ₹ 6,181.05000 | ₹ 6,181.05 |
Stock:
Distributor: 115
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 250 | ₹ 4,595.96000 | ₹ 11,48,990.00 |
| 100 | ₹ 4,765.06000 | ₹ 4,76,506.00 |
| 50 | ₹ 4,837.15000 | ₹ 2,41,857.50 |
| 25 | ₹ 4,911.02000 | ₹ 1,22,775.50 |
| 10 | ₹ 5,350.68000 | ₹ 53,506.80 |
| 5 | ₹ 5,515.33000 | ₹ 27,576.65 |
| 1 | ₹ 6,181.05000 | ₹ 6,181.05 |
Stock:
Distributor: 123
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 5,913.16000 | ₹ 5,913.16 |
| 5 | ₹ 5,754.74000 | ₹ 28,773.70 |
| 10 | ₹ 5,595.43000 | ₹ 55,954.30 |
| 25 | ₹ 5,411.20000 | ₹ 1,35,280.00 |
| 50 | ₹ 5,374.71000 | ₹ 2,68,735.50 |
| 100 | ₹ 5,340.89000 | ₹ 5,34,089.00 |
Stock:
Distributor: 108
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 5,913.16000 | ₹ 5,913.16 |
| 10 | ₹ 5,595.43000 | ₹ 55,954.30 |
| 25 | ₹ 5,411.20000 | ₹ 1,35,280.00 |
| 50 | ₹ 5,374.71000 | ₹ 2,68,735.50 |
| 100 | ₹ 5,340.89000 | ₹ 5,34,089.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | 175 | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Transformer Turn Ratio | - | |
| Primary Coil Impedance | 5.1k | |
| Secondary Coil Impedance | 8 | |
| Primary Winding DC Resistance | 380Ohm | |
| Secondary Winding DC Resistance | 750mOhm | |
| Voltage Transformer Design | Push-Pull Audiophile, Ultra-Linear - Tube Output | |
| Operational Hz Spectrum | 50Hz ~ 12kHz | |
| Audio Frequency Curve | -4dB | |
| Isolation Barrier Voltage | 1500V | |
| Signal Insertion Attenuation | - | |
| Reflection Loss dB | - | |
| Signal Power Strength | 25W | |
| Ambient Temp Range | -40°C ~ 105°C | |
| Certification Body | - | |
| Attachment Mounting Style | Chassis Mount | |
| Package Size Specs | 3.125" L x 2.120" W (79.38mm x 53.85mm) | |
| Maximum Mounted Height | 2.308" (58.62mm) | |
| Lead Termination Type | Wire Leads |
Description
Records primary DCR at 380Ohm. Specifies secondary DCR as 750mOhm. Offers a 50Hz ~ 12kHz frequency spectrum for broad-spectrum applications. Produces a -4dB frequency response for dependable signal integrity. Maximum installed height of 2.308" (58.62mm) for components affixed to the board. The primary impedance is rated at 5.1k Ohms for electrical design considerations. The secondary impedance is established at 8 Ohms to achieve optimal load compatibility. Mounting configuration Chassis Mount for structural stability. Temperature range -40°C ~ 105°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Signal strength 25W to meet operational needs. Product status Active concerning availability and lifecycle. Classification series for the product or component 175. Details on package size 3.125" L x 2.120" W (79.38mm x 53.85mm) for electrical or mechanical components. Measurement dimensions 3.125" L x 2.120" W (79.38mm x 53.85mm) for component specifications. Type of termination Wire Leads for connector or device. Design of transformer Push-Pull Audiophile, Ultra-Linear - Tube Output for electrical conversion. Isolation voltage 1500V for electrical safety.
