Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Box | |
| Availability Status | Active | |
| Indicator Light Hue | White, Cool | |
| Total Light Output Lumens | 630lm | |
| Linear Length Dimension | 9.25" (235.0mm) | |
| Width Height Profile | 1.46" x 1.57" (37.0mm x 40.0mm) | |
| Nominal Power Rating | 6.0W | |
| Power Supply Voltage | 24VDC | |
| Key Product Highlights | - | |
| Casing Build Material | Aluminum (Al) | |
| Expected Service Hours | - | |
| Lead Termination Type | Connector (M12) | |
| Ambient Temp Range | -30°C ~ 50°C | |
| Dust Water Resistance Rating | IP67 - Dust Tight, Waterproof | |
| Optical Element Category | Flat, Diffused | |
| Certification Body | CE, cULus |
Description
Complies with the criteria of entities acknowledged as CE, cULus. Constructed from Aluminum (Al) material to guarantee strength and reliability. Offers White, Cool light color for better visual differentiation. Rated with IP IP67 - Dust Tight, Waterproof to safeguard against dust and moisture penetration. Overall length 9.25" (235.0mm) for size indication. Features Flat, Diffused lens type tailored for specific application requirements. The overall luminous output 630lm indicating total light generation. Temperature range -30°C ~ 50°C for environmental conditions impacting thermal efficiency. Type of housing Box for safeguarding or transporting components. Energy requirement 6.0W for device functionality. Designated power 6.0W to meet compliance standards. Product status Active concerning availability and lifecycle. Size dimensions width x height 1.46" x 1.57" (37.0mm x 40.0mm) for specifications. Voltage requirement 24VDC for electrical specifications. Type of termination Connector (M12) for connector or device. Voltage supply 24VDC for device operation.
