Description

Complies with the criteria of entities acknowledged as cUR, UR. Indicates 1 channels present for improved performance. Ensures a minimum common-mode transient immunity of 25kV/µs to reduce interference. Offers a maximum DC forward current (If) specified at 25 mA. Facilitates a maximum output current level set as 400ns, 400ns. Offers information on high and low output current settings at 500mA, 500mA. Features peak output current measured at 500mA. Mounting configuration Through Hole for structural stability. Overall channels 1 for input/output or communication purposes. Temperature range -40°C ~ 110°C for environmental conditions impacting thermal efficiency. Type of housing Tube for safeguarding or transporting components. Style of the enclosure/case 8-DIP (0.300", 7.62mm) that offers mechanical and thermal protection. Type of package 8-DIP that preserves the integrity of the device. Product status Active concerning availability and lifecycle. Highest tpLH/tpHL latency 400ns, 400ns for rapid applications. Maximum pulse width deviation 200ns to maintain signal integrity. Typical rise and fall duration 100ns, 100ns for signal transitions. Supplier package type 8-DIP for component selection. Voltage requirement 15V ~ 32V for electrical specifications. The primary technology platform Optical Coupling linked to the product category. Common forward voltage Vf 1.3V for diode operation. Isolation voltage 5300Vrms for electrical safety. The supply voltage output 15V ~ 32V used to power the device.
