Description

Complies with the criteria of entities acknowledged as CQC, CSA, UR, VDE. Indicates 2 channels present for improved performance. Ensures a minimum common-mode transient immunity of 20kV/µs to reduce interference. Facilitates a maximum output current level set as 60ns, 60ns. Offers information on high and low output current settings at 2A, 4A. Features peak output current measured at 4A. Evaluated as Automotive grade for quality control. Mounting configuration Surface Mount for structural stability. Overall channels 2 for input/output or communication purposes. Temperature range -40°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR)Cut Tape (CT)Digi-Reel® for safeguarding or transporting components. Style of the enclosure/case 14-VFLGA that offers mechanical and thermal protection. Type of package 14-LGA (5x5) that preserves the integrity of the device. Product status Active concerning availability and lifecycle. Highest tpLH/tpHL latency 60ns, 60ns for rapid applications. Maximum pulse width deviation 5.6ns to maintain signal integrity. Certification AEC-Q100 for compliance with testing or regulatory standards. Typical rise and fall duration 12ns, 12ns (Max) for signal transitions. Supplier package type 14-LGA (5x5) for component selection. Voltage requirement 9.4V ~ 24V for electrical specifications. The primary technology platform Capacitive Coupling linked to the product category. Isolation voltage 2500Vrms for electrical safety. The supply voltage output 9.4V ~ 24V used to power the device.
