Description

Complies with the criteria of entities acknowledged as CSA, IEC/EN/DIN, UR. Indicates 1 channels present for improved performance. Ensures a minimum common-mode transient immunity of 100kV/µs to reduce interference. Offers a maximum DC forward current (If) specified at 25 mA. Facilitates a maximum output current level set as 150ns, 150ns. Offers information on high and low output current settings at 4A, 4A. Features peak output current measured at 5A. Mounting configuration Surface Mount for structural stability. Overall channels 1 for input/output or communication purposes. Temperature range -40°C ~ 110°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR)Cut Tape (CT)Digi-Reel® for safeguarding or transporting components. Style of the enclosure/case 8-SOIC (0.378", 9.60mm Width) that offers mechanical and thermal protection. Type of package 8-SO Stretched that preserves the integrity of the device. Product status Active concerning availability and lifecycle. Highest tpLH/tpHL latency 150ns, 150ns for rapid applications. Maximum pulse width deviation 80ns to maintain signal integrity. Typical rise and fall duration 20ns, 10ns for signal transitions. Supplier package type 8-SO Stretched for component selection. Voltage requirement 15V ~ 30V for electrical specifications. The primary technology platform Optical Coupling linked to the product category. Common forward voltage Vf 1.45V for diode operation. Isolation voltage 5000Vrms for electrical safety. The supply voltage output 15V ~ 30V used to power the device.
