Stock:
Distributor: 118
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 4,299.59000 | ₹ 4,299.59 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | TubeTube | |
| Availability Status | Obsolete | |
| Core Technology Platform | Capacitive Coupling | |
| Device Type Classification | General Purpose | |
| Galvanic Isolation Supply | No | |
| Audio/Video Channel Count | 2 | |
| Dual Side Input Counts | 2/2 | |
| Signal Path Design | Bidirectional | |
| Isolation Barrier Voltage | 1500Vrms | |
| Minimum Surge Tolerance | 1.6kV/µs (Typ) | |
| Transfer Speed Mbps | 80MBd | |
| Max Low-to-High/High-to-Low Delay | 40ns, 40ns | |
| Max Pulse Skew | 6ns | |
| Typical Edge Transition Time | 9ns, 9ns | |
| Power Supply Voltage | 3V ~ 5.5V | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Ambient Temp Range | -40°C ~ 85°C | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 28-SOIC (0.295", 7.50mm Width), 8 Leads | |
| Vendor Package Type | 8-SOIC |
Description
Organized by channel type referred to as Bidirectional. Indicates 2 channels present for improved performance. Ensures a minimum common-mode transient immunity of 1.6kV/µs (Typ) to reduce interference. Facilitates a maximum output current level set as 40ns, 40ns. Delivers a data transfer rate measured at 80MBd for rapid operations. Demonstrates a sampling rate capability indicated as 80MBd. Inputs on side 1/side 2 permit 2/2 configuration. Supplies No isolated power to maintain safe circuitry. Mounting configuration Surface Mount for structural stability. Overall channels 2 for input/output or communication purposes. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing TubeTube for safeguarding or transporting components. Style of the enclosure/case 28-SOIC (0.295", 7.50mm Width), 8 Leads that offers mechanical and thermal protection. Type of package 8-SOIC that preserves the integrity of the device. Product status Obsolete concerning availability and lifecycle. Highest tpLH/tpHL latency 40ns, 40ns for rapid applications. Maximum pulse width deviation 6ns to maintain signal integrity. Typical rise and fall duration 9ns, 9ns for signal transitions. Supplier package type 8-SOIC for component selection. Voltage requirement 3V ~ 5.5V for electrical specifications. The primary technology platform Capacitive Coupling linked to the product category. Type classification General Purpose for specifications. Isolation voltage 1500Vrms for electrical safety. Voltage supply 3V ~ 5.5V for device operation.
