Description

Organized by channel type referred to as Unidirectional. Indicates 4 channels present for improved performance. Ensures a minimum common-mode transient immunity of 40kV/µs to reduce interference. Facilitates a maximum output current level set as 18ns, 23ns. Delivers a data transfer rate measured at 100Mbps for rapid operations. Demonstrates a sampling rate capability indicated as 100Mbps. Inputs on side 1/side 2 permit 3/1 configuration. Supplies No isolated power to maintain safe circuitry. Mounting configuration Surface Mount for structural stability. Overall channels 4 for input/output or communication purposes. Temperature range -40°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Tube for safeguarding or transporting components. Style of the enclosure/case 24-SOIC (0.295", 7.50mm Width) that offers mechanical and thermal protection. Type of package 24-SOIC that preserves the integrity of the device. Product status Active concerning availability and lifecycle. Highest tpLH/tpHL latency 18ns, 23ns for rapid applications. Maximum pulse width deviation 7ns to maintain signal integrity. Typical rise and fall duration 2.5ns, 2.5ns for signal transitions. Supplier package type 24-SOIC for component selection. Voltage requirement 3V ~ 5.5V for electrical specifications. The primary technology platform Capacitive Coupling linked to the product category. Type classification General Purpose for specifications. Isolation voltage 5000Vrms for electrical safety. Voltage supply 3V ~ 5.5V for device operation.
