Description

Organized by channel type referred to as Unidirectional. Indicates 1 channels present for improved performance. Ensures a minimum common-mode transient immunity of 20kV/µs to reduce interference. Facilitates a maximum output current level set as 60ns, 60ns. Delivers a data transfer rate measured at 1Mbps for rapid operations. Demonstrates a sampling rate capability indicated as 1Mbps. Inputs on side 1/side 2 permit 1/0 configuration. Supplies No isolated power to maintain safe circuitry. Mounting configuration Surface Mount for structural stability. Overall channels 1 for input/output or communication purposes. Temperature range -40°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Tube for safeguarding or transporting components. Style of the enclosure/case 6-SOIC (0.295", 7.50mm Width) that offers mechanical and thermal protection. Type of package 6-SDIP Gull Wing that preserves the integrity of the device. Product status Active concerning availability and lifecycle. Highest tpLH/tpHL latency 60ns, 60ns for rapid applications. Maximum pulse width deviation 20ns to maintain signal integrity. Typical rise and fall duration 15ns, 5ns for signal transitions. Supplier package type 6-SDIP Gull Wing for component selection. Voltage requirement 3V ~ 30V for electrical specifications. The primary technology platform Capacitive Coupling linked to the product category. Type classification General Purpose for specifications. Isolation voltage 5000Vrms for electrical safety. Voltage supply 3V ~ 30V for device operation.
