Description

Organized by channel type referred to as Unidirectional. Indicates 2 channels present for improved performance. Ensures a minimum common-mode transient immunity of 35kV/µs to reduce interference. Facilitates a maximum output current level set as 35ns, 35ns. Delivers a data transfer rate measured at 1Mbps for rapid operations. Demonstrates a sampling rate capability indicated as 1Mbps. Inputs on side 1/side 2 permit 2/0 configuration. Supplies No isolated power to maintain safe circuitry. Mounting configuration Surface Mount for structural stability. Overall channels 2 for input/output or communication purposes. Temperature range -40°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Tray for safeguarding or transporting components. Style of the enclosure/case 8-VDFN that offers mechanical and thermal protection. Type of package 8-DFN (5x4) that preserves the integrity of the device. Product status Obsolete concerning availability and lifecycle. Highest tpLH/tpHL latency 35ns, 35ns for rapid applications. Maximum pulse width deviation 25ns to maintain signal integrity. Typical rise and fall duration 2.5ns, 2.5ns for signal transitions. Supplier package type 8-DFN (5x4) for component selection. Voltage requirement 2.5V ~ 5.5V for electrical specifications. The primary technology platform Capacitive Coupling linked to the product category. Type classification General Purpose for specifications. Isolation voltage 2500Vrms for electrical safety. Voltage supply 2.5V ~ 5.5V for device operation.
