Description

Supplies peak output current defined as 13.5A. Features fault protection capabilities quantified at Current Limiting (Adjustable), Over Temperature, Over Voltage, UVLO. Equipped with features categorized as Slew Rate Controlled. Configured with Non-Inverting input type for diverse applications. Designed for On/Off ease of use and user interaction. Mounting configuration Surface Mount, Wettable Flank for structural stability. Overall outputs 1 for device connections. Resistance during the on-state 17mOhm for effective conduction. Temperature range -40°C ~ 125°C (TJ) for environmental conditions impacting thermal efficiency. Preferences High Side for establishing system output configurations. Type N-Channel for ensuring compatibility with output systems. Type of housing Tape & Reel (TR)Cut Tape (CT)Digi-Reel® for safeguarding or transporting components. Style of the enclosure/case 10-WFDFN Exposed Pad that offers mechanical and thermal protection. Type of package DFN3030-10 that preserves the integrity of the device. Product status Active concerning availability and lifecycle. Input-output ratio 1:1 for electrical or mechanical conversion. Mean Rds(on) 17mOhm for MOSFET functionality. Supplier package type DFN3030-10 for component selection. Voltage requirement Not Required for electrical specifications. Classification of switch General Purpose for equipment selection. Load voltage 9V ~ 18V required for devices. Vcc/Vdd voltage supply Not Required for electronic devices.
