Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | LDU08 (8W) | |
| IC Encapsulation Type | Box | |
| Availability Status | Obsolete | |
| Device Type Classification | Constant Current | |
| Circuit Topology Design | Buck | |
| Signal Output Quantity | 1 | |
| Minimum Input Voltage | 7V | |
| Maximum Input Voltage | 30V | |
| Delivery Output Volts | 2 ~ 28V | |
| Peak Output Current | 350mA | |
| Wattage Power Level | 8 W | |
| Isolation Barrier Voltage | - | |
| Brightness Control | Analog, PWM | |
| Key Product Highlights | Remote On/Off, SCP | |
| Performance Rating Specs | IP67 | |
| Ambient Temp Range | -40°C ~ 85°C | |
| Performance Efficiency Rating | 95% | |
| Lead Termination Type | Wire Leads | |
| Package Size Specs | 0.92" L x 0.55" W x 0.40" H (23.4mm x 14.0mm x 10.2mm) | |
| Certification Body | EN | |
| Compliance Standard ID | - |
Description
Complies with the criteria of entities acknowledged as EN. Supplies peak output current defined as 350mA. Includes options for brightness adjustment classified as Analog, PWM. Offers an efficiency rating calculated at 95%. Equipped with features categorized as Remote On/Off, SCP. The input voltage established at 7V for reliable performance. Overall outputs 1 for device connections. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Voltage 2 ~ 28V for optimal output electric potential. Type of housing Box for safeguarding or transporting components. Power measured in watts 8 W for optimal operation. Product status Obsolete concerning availability and lifecycle. Criteria IP67 for electrical, mechanical, or environmental performance. Classification series for the product or component LDU08 (8W). Details on package size 0.92" L x 0.55" W x 0.40" H (23.4mm x 14.0mm x 10.2mm) for electrical or mechanical components. Measurement dimensions 0.92" L x 0.55" W x 0.40" H (23.4mm x 14.0mm x 10.2mm) for component specifications. Type of termination Wire Leads for connector or device. Layout design Buck for electrical systems or configurations. Type classification Constant Current for specifications. Maximum input voltage 30V for safeguarding. Minimum input voltage 7V for operation. The output voltage 2 ~ 28V for electrical systems.
