Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | Tariff may apply if shipping to the United States | |
| Product Series Line | PDA (80W) | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Device Type Classification | Constant Current | |
| Circuit Topology Design | AC DC Converter | |
| Signal Output Quantity | 1 | |
| Minimum Input Voltage | 120VAC | |
| Maximum Input Voltage | 277VAC | |
| Delivery Output Volts | 34 ~ 48V | |
| Peak Output Current | 1.67A | |
| Wattage Power Level | 80 W | |
| Isolation Barrier Voltage | 4.242 kV | |
| Brightness Control | Analog | |
| Key Product Highlights | OCP, OVP, SCP | |
| Performance Rating Specs | IP65 | |
| Ambient Temp Range | -40°C ~ 60°C | |
| Performance Efficiency Rating | 85% | |
| Lead Termination Type | Wire Leads | |
| Package Size Specs | 9.50" L x 1.70" W x 1.20" H (241.0mm x 43.0mm x 30.5mm) | |
| Certification Body | CE, cULus | |
| Compliance Standard ID | - |
Description
Complies with the criteria of entities acknowledged as CE, cULus. Assesses resistance at forward current Tariff may apply if shipping to the United States for LED or diode testing. Supplies peak output current defined as 1.67A. Includes options for brightness adjustment classified as Analog. Offers an efficiency rating calculated at 85%. Equipped with features categorized as OCP, OVP, SCP. The input voltage established at 120VAC for reliable performance. Overall outputs 1 for device connections. Temperature range -40°C ~ 60°C for environmental conditions impacting thermal efficiency. Voltage 34 ~ 48V for optimal output electric potential. Type of housing Bulk for safeguarding or transporting components. Power measured in watts 80 W for optimal operation. Product status Obsolete concerning availability and lifecycle. Criteria IP65 for electrical, mechanical, or environmental performance. Classification series for the product or component PDA (80W). Details on package size 9.50" L x 1.70" W x 1.20" H (241.0mm x 43.0mm x 30.5mm) for electrical or mechanical components. Measurement dimensions 9.50" L x 1.70" W x 1.20" H (241.0mm x 43.0mm x 30.5mm) for component specifications. The classification for import duties Tariff may apply if shipping to the United States related to import and export transactions. Type of termination Wire Leads for connector or device. Layout design AC DC Converter for electrical systems or configurations. Type classification Constant Current for specifications. Maximum Vce(on) at Vge Tariff may apply if shipping to the United States for transistor specifications. Maximum input voltage 277VAC for safeguarding. Minimum input voltage 120VAC for operation. Isolation voltage 4.242 kV for electrical safety. The output voltage 34 ~ 48V for electrical systems.
