Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tube | |
| Availability Status | Active | |
| Device Type Classification | Standard (General Purpose) | |
| Component Element Total | 1 | |
| Exit Signal Category | CMOS | |
| Single or Dual Supply Option | 2.45V ~ 5.25V | |
| Max Input Offset Volts | 5.5mV @ 5V | |
| Peak Bias Input Current | 1.6µA @ 5V | |
| Typical Output Amperage | 19mA @ 5V | |
| Maximum Idle Current | 2.65mA | |
| Typical Rejection Ratios | - | |
| Worst-Case Delay Time | 5.3ns | |
| Switching Threshold Gap | - | |
| Ambient Temp Range | -40°C ~ 85°C | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Component Housing Style | 12-WFQFN Exposed Pad | |
| Attachment Mounting Style | Surface Mount | |
| Vendor Package Type | 12-QFN (3x3) |
Description
Displays the maximum input bias current of 1.6µA @ 5V. Records typical output current at 19mA @ 5V. Provides maximum quiescent current of 2.65mA. Mounting configuration Surface Mount for structural stability. Total elements 1 present in circuits or arrays. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Type CMOS for ensuring compatibility with output systems. Type of housing Tube for safeguarding or transporting components. Style of the enclosure/case 12-WFQFN Exposed Pad that offers mechanical and thermal protection. Type of package 12-QFN (3x3) that preserves the integrity of the device. Product status Active concerning availability and lifecycle. Maximum signal latency 5.3ns for critical timing. Supplier package type 12-QFN (3x3) for component selection. Type classification Standard (General Purpose) for specifications. Maximum input offset voltage 5.5mV @ 5V for precise circuits. Option to select between single or dual voltage supply ± 2.45V ~ 5.25V for different devices.
