Stock:
Distributor: 118
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 4168 | ₹ 14.95000 | ₹ 62,311.60 |
| 1390 | ₹ 17.09000 | ₹ 23,755.10 |
| 1 | ₹ 85.44000 | ₹ 85.44 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Obsolete | |
| Circuit Switching Type | SPST - NO | |
| Signal Mux/Demux Channels | 1:1 | |
| Electrical Circuit Count | 1 | |
| Maximum On Resistance | 10Ohm | |
| Inter-Channel Resistance Match | - | |
| Single Positive Supply | 2V ~ 5.5V | |
| Dual Symmetric Supply | - | |
| Max On/Off Switching Time | 4ns, 7.5ns | |
| 3dB Bandwidth | 180MHz | |
| Charge Transfer Effect | - | |
| Off-State Channel Capacitance | 3pF | |
| Max Off-State Leakage | 100nA | |
| Signal Interference Level | - | |
| Ambient Temp Range | -55°C ~ 125°C (TA) | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | SC-74A, SOT-753 | |
| Vendor Package Type | SOT-23-5 |
Description
Delivers a -3dB bandwidth of 180MHz to maintain reliable signal quality. Offers off-state channel capacitance of 3pF. Highlights the maximum off-state leakage (IS(off)) rated at 100nA. Mounting configuration Surface Mount for structural stability. Mux/demux pathway 1:1 for signal control. The total number of circuits stands at 1 for electrical or electronic setups. Resistance during the on-state 10Ohm for effective conduction. Peak resistance in the on-state 10Ohm for electrical efficiency. Temperature range -55°C ~ 125°C (TA) for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case SC-74A, SOT-753 that offers mechanical and thermal protection. Type of package SOT-23-5 that preserves the integrity of the device. Product status Obsolete concerning availability and lifecycle. Supplier package type SOT-23-5 for component selection. Circuit switch SPST - NO for functional operations. Maximum on/off switching duration Ton/Toff 4ns, 7.5ns for timing accuracy. Single voltage supply for electronic devices at V+ 2V ~ 5.5V.
