Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 4000 | ₹ 112.15000 | ₹ 4,48,600.00 |
| 1000 | ₹ 127.67000 | ₹ 1,27,670.00 |
| 500 | ₹ 131.59000 | ₹ 65,795.00 |
| 250 | ₹ 136.35000 | ₹ 34,087.50 |
| 100 | ₹ 144.25000 | ₹ 14,425.00 |
| 25 | ₹ 160.81000 | ₹ 4,020.25 |
| 10 | ₹ 175.87000 | ₹ 1,758.70 |
| 1 | ₹ 235.82000 | ₹ 235.82 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Cut Tape (CT) | |
| Availability Status | Active | |
| Circuit Switching Type | SPST | |
| Signal Mux/Demux Channels | 1:1 | |
| Electrical Circuit Count | 4 | |
| Maximum On Resistance | 1Ohm | |
| Inter-Channel Resistance Match | 40mOhm (Typ) | |
| Single Positive Supply | 1.8V ~ 5.5V | |
| Dual Symmetric Supply | - | |
| Max On/Off Switching Time | 50ns (Typ), 15ns (Typ) | |
| 3dB Bandwidth | 30MHz | |
| Charge Transfer Effect | - | |
| Off-State Channel Capacitance | 80pF | |
| Max Off-State Leakage | 1µA | |
| Signal Interference Level | - | |
| Ambient Temp Range | -40°C ~ 125°C | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 16-TSSOP (0.173", 4.40mm Width) | |
| Vendor Package Type | 16-TSSOP |
Description
Delivers a -3dB bandwidth of 30MHz to maintain reliable signal quality. Offers off-state channel capacitance of 80pF. Ensures ΔRon alignment accuracy defined at 40mOhm (Typ). Highlights the maximum off-state leakage (IS(off)) rated at 1µA. Mounting configuration Surface Mount for structural stability. Mux/demux pathway 1:1 for signal control. The total number of circuits stands at 4 for electrical or electronic setups. Resistance during the on-state 1Ohm for effective conduction. Peak resistance in the on-state 1Ohm for electrical efficiency. Temperature range -40°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Cut Tape (CT) for safeguarding or transporting components. Style of the enclosure/case 16-TSSOP (0.173", 4.40mm Width) that offers mechanical and thermal protection. Type of package 16-TSSOP that preserves the integrity of the device. Product status Active concerning availability and lifecycle. Supplier package type 16-TSSOP for component selection. Circuit switch SPST for functional operations. Maximum on/off switching duration Ton/Toff 50ns (Typ), 15ns (Typ) for timing accuracy. Single voltage supply for electronic devices at V+ 1.8V ~ 5.5V.
