Stock:
Distributor: 145
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 2225 | ₹ 12.02000 | ₹ 26,744.50 |
| 1665 | ₹ 13.40000 | ₹ 22,311.00 |
| 1285 | ₹ 13.86000 | ₹ 17,810.10 |
| 935 | ₹ 14.32000 | ₹ 13,389.20 |
| 605 | ₹ 14.78000 | ₹ 8,941.90 |
| 250 | ₹ 18.01000 | ₹ 4,502.50 |
Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 40000 | ₹ 17.84000 | ₹ 7,13,600.00 |
| 28000 | ₹ 17.99000 | ₹ 5,03,720.00 |
| 20000 | ₹ 18.14000 | ₹ 3,62,800.00 |
| 12000 | ₹ 18.41000 | ₹ 2,20,920.00 |
| 8000 | ₹ 18.65000 | ₹ 1,49,200.00 |
| 4000 | ₹ 19.13000 | ₹ 76,520.00 |
| 1000 | ₹ 20.43000 | ₹ 20,430.00 |
| 500 | ₹ 21.29000 | ₹ 10,645.00 |
| 250 | ₹ 22.33000 | ₹ 5,582.50 |
| 100 | ₹ 24.07000 | ₹ 2,407.00 |
| 25 | ₹ 27.71000 | ₹ 692.75 |
| 10 | ₹ 31.03000 | ₹ 310.30 |
| 1 | ₹ 43.75000 | ₹ 43.75 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Cut Tape (CT) | |
| Availability Status | Active | |
| Circuit Switching Type | SP4T | |
| Signal Mux/Demux Channels | 4:1 | |
| Electrical Circuit Count | 1 | |
| Maximum On Resistance | 30Ohm | |
| Inter-Channel Resistance Match | 1Ohm (Typ) | |
| Single Positive Supply | 2.5V ~ 5.5V | |
| Dual Symmetric Supply | - | |
| Max On/Off Switching Time | 90ns (Typ), 70ns (Typ) | |
| 3dB Bandwidth | 180MHz | |
| Charge Transfer Effect | 6pC | |
| Off-State Channel Capacitance | 12.7pF | |
| Max Off-State Leakage | 100nA | |
| Signal Interference Level | -110dB @ 1MHz | |
| Ambient Temp Range | -40°C ~ 125°C (TA) | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) | |
| Vendor Package Type | 10-MSOP |
Description
Delivers a -3dB bandwidth of 180MHz to maintain reliable signal quality. Offers off-state channel capacitance of 12.7pF. Ensures ΔRon alignment accuracy defined at 1Ohm (Typ). Provides charge injection capability rated at 6pC. Minimizes crosstalk with a level of -110dB @ 1MHz for improved signal quality. Highlights the maximum off-state leakage (IS(off)) rated at 100nA. Mounting configuration Surface Mount for structural stability. Mux/demux pathway 4:1 for signal control. The total number of circuits stands at 1 for electrical or electronic setups. Resistance during the on-state 30Ohm for effective conduction. Peak resistance in the on-state 30Ohm for electrical efficiency. Temperature range -40°C ~ 125°C (TA) for environmental conditions impacting thermal efficiency. Type of housing Cut Tape (CT) for safeguarding or transporting components. Style of the enclosure/case 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) that offers mechanical and thermal protection. Type of package 10-MSOP that preserves the integrity of the device. Product status Active concerning availability and lifecycle. Supplier package type 10-MSOP for component selection. Circuit switch SP4T for functional operations. Maximum on/off switching duration Ton/Toff 90ns (Typ), 70ns (Typ) for timing accuracy. Single voltage supply for electronic devices at V+ 2.5V ~ 5.5V.
