Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 28000 | ₹ 23.87000 | ₹ 6,68,360.00 |
| 20000 | ₹ 24.06000 | ₹ 4,81,200.00 |
| 12000 | ₹ 24.40000 | ₹ 2,92,800.00 |
| 8000 | ₹ 24.70000 | ₹ 1,97,600.00 |
| 4000 | ₹ 25.31000 | ₹ 1,01,240.00 |
| 1000 | ₹ 26.93000 | ₹ 26,930.00 |
| 500 | ₹ 28.02000 | ₹ 14,010.00 |
| 250 | ₹ 29.33000 | ₹ 7,332.50 |
| 100 | ₹ 31.52000 | ₹ 3,152.00 |
| 25 | ₹ 36.09000 | ₹ 902.25 |
| 10 | ₹ 40.29000 | ₹ 402.90 |
| 1 | ₹ 56.26000 | ₹ 56.26 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tape & Reel (TR)Cut Tape (CT) | |
| Availability Status | Active | |
| Circuit Switching Type | SPDT | |
| Signal Mux/Demux Channels | 2:1 | |
| Electrical Circuit Count | 2 | |
| Maximum On Resistance | 7Ohm | |
| Inter-Channel Resistance Match | 150mOhm (Typ) | |
| Single Positive Supply | 2.5V ~ 5.5V | |
| Dual Symmetric Supply | - | |
| Max On/Off Switching Time | 15ns (Typ), 10ns (Typ) | |
| 3dB Bandwidth | 400MHz | |
| Charge Transfer Effect | 15pC | |
| Off-State Channel Capacitance | 10pF | |
| Max Off-State Leakage | 1µA | |
| Signal Interference Level | -52dB @ 10MHz | |
| Ambient Temp Range | -40°C ~ 85°C (TA) | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) | |
| Vendor Package Type | 10-MSOP |
Description
Delivers a -3dB bandwidth of 400MHz to maintain reliable signal quality. Offers off-state channel capacitance of 10pF. Ensures ΔRon alignment accuracy defined at 150mOhm (Typ). Provides charge injection capability rated at 15pC. Minimizes crosstalk with a level of -52dB @ 10MHz for improved signal quality. Highlights the maximum off-state leakage (IS(off)) rated at 1µA. Mounting configuration Surface Mount for structural stability. Mux/demux pathway 2:1 for signal control. The total number of circuits stands at 2 for electrical or electronic setups. Resistance during the on-state 7Ohm for effective conduction. Peak resistance in the on-state 7Ohm for electrical efficiency. Temperature range -40°C ~ 85°C (TA) for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR)Cut Tape (CT) for safeguarding or transporting components. Style of the enclosure/case 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) that offers mechanical and thermal protection. Type of package 10-MSOP that preserves the integrity of the device. Product status Active concerning availability and lifecycle. Supplier package type 10-MSOP for component selection. Circuit switch SPDT for functional operations. Maximum on/off switching duration Ton/Toff 15ns (Typ), 10ns (Typ) for timing accuracy. Single voltage supply for electronic devices at V+ 2.5V ~ 5.5V.
