Stock:
Distributor: 114
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 27,987.83000 | ₹ 27,987.83 |
| 2 | ₹ 27,188.61000 | ₹ 54,377.22 |
| 5 | ₹ 26,433.00000 | ₹ 1,32,165.00 |
| 9 | ₹ 25,375.68000 | ₹ 2,28,381.12 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | D40Z | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Device Type Classification | Magnetic | |
| Electrical Pathway | SPST-NO | |
| Ampere Capacity Rating | 10mA (DC) | |
| Max Voltage Specification | 24VDC | |
| Power Supply Voltage | 24VDC | |
| Retention Grip Strength | - | |
| Activator Mechanism Type | Non-Contact | |
| Lead Termination Type | Cable Leads | |
| Key Product Highlights | - | |
| Activation Threshold | 5mm | |
| Deactivation Threshold | 15mm | |
| Tubing Thread Gauge | - | |
| Ambient Temp Range | -10°C ~ 65°C | |
| Dust Water Resistance Rating | IP67 - Dust Tight, Waterproof | |
| Certification Body | CE, cULus, TUV |
Description
Incorporates a Non-Contact actuator type to fulfill the desired function. Complies with the criteria of entities acknowledged as CE, cULus, TUV. Configured for circuit type described as SPST-NO. Sets the ampere rating to 10mA (DC). Rated with IP IP67 - Dust Tight, Waterproof to safeguard against dust and moisture penetration. Must operate at 5mm for reliable performance. Should turn off at 15mm for safe mechanical or electrical operation. Temperature range -10°C ~ 65°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Classification series for the product or component D40Z. Voltage requirement 24VDC for electrical specifications. Type of termination Cable Leads for connector or device. Type classification Magnetic for specifications. Voltage supply 24VDC for device operation. Voltage specification 24VDC for electronic devices.
