Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | LOPL | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Obsolete | |
| Visual Hue | White | |
| Color Temperature Kelvin | - | |
| Flux at 85C Test Current | - | |
| Flux at 25C Test Current | 43lm (Typ) | |
| Testing Current Value | 350mA | |
| Typical Forward Voltage | 3.8V | |
| Efficiency Lumens per Watt | 32 lm/W | |
| Color Accuracy Rating | 85 (Typ) | |
| Maximum Amp Rating | 350mA | |
| Display View Cone Degrees | - | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 2-SMD, Gull Wing Exposed Pad | |
| Vendor Package Type | - | |
| Package Size Specs | 0.315" Dia (8.00mm) | |
| Maximum Mounted Height | 0.087" (2.20mm) |
Description
Has a CRI score of 85 (Typ) for accurate color depiction. Offered in a shade referred to as White to enhance the system's aesthetics. Indicates the maximum allowable current rating at 350mA. Assessed at current levels outlined by 350mA. Presents flux at 25°C for the given test current of 43lm (Typ). Maximum installed height of 0.087" (2.20mm) for components affixed to the board. The lumens per watt 32 lm/W evaluated at the testing current to determine lighting efficiency. Mounting configuration Surface Mount for structural stability. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 2-SMD, Gull Wing Exposed Pad that offers mechanical and thermal protection. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component LOPL. Details on package size 0.315" Dia (8.00mm) for electrical or mechanical components. Measurement dimensions 0.315" Dia (8.00mm) for component specifications. Common forward voltage Vf 3.8V for diode operation.
