Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | Tariff may apply if shipping to the United States | |
| Product Series Line | DURIS® E 3 | |
| IC Encapsulation Type | Tape & Reel (TR)Cut Tape (CT)Digi-Reel® | |
| Availability Status | Active | |
| Visual Hue | White, Cool | |
| Color Temperature Kelvin | 6500K | |
| Flux at 85C Test Current | - | |
| Flux at 25C Test Current | 37lm (32lm ~ 41lm) | |
| Testing Current Value | 65mA | |
| Typical Forward Voltage | 2.95V | |
| Efficiency Lumens per Watt | 193 lm/W | |
| Color Accuracy Rating | 80 | |
| Maximum Amp Rating | 150mA | |
| Display View Cone Degrees | 120° | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 1106 (2815 Metric) | |
| Vendor Package Type | SMD | |
| Package Size Specs | 0.110" L x 0.055" W (2.80mm x 1.40mm) | |
| Maximum Mounted Height | 0.028" (0.70mm) |
Description
Offers a correlated color temperature of 6500KK to create the desired lighting ambiance. Has a CRI score of 80 for accurate color depiction. Assesses resistance at forward current Tariff may apply if shipping to the United States for LED or diode testing. Offered in a shade referred to as White, Cool to enhance the system's aesthetics. Indicates the maximum allowable current rating at 150mA. Assessed at current levels outlined by 65mA. Presents flux at 25°C for the given test current of 37lm (32lm ~ 41lm). Maximum installed height of 0.028" (0.70mm) for components affixed to the board. Employs 6500K light type for maximum brightness. The lumens per watt 193 lm/W evaluated at the testing current to determine lighting efficiency. Mounting configuration Surface Mount for structural stability. Type of housing Tape & Reel (TR)Cut Tape (CT)Digi-Reel® for safeguarding or transporting components. Style of the enclosure/case 1106 (2815 Metric) that offers mechanical and thermal protection. Type of package SMD that preserves the integrity of the device. Product status Active concerning availability and lifecycle. Classification series for the product or component DURIS® E 3. Details on package size 0.110" L x 0.055" W (2.80mm x 1.40mm) for electrical or mechanical components. Measurement dimensions 0.110" L x 0.055" W (2.80mm x 1.40mm) for component specifications. Supplier package type SMD for component selection. The classification for import duties Tariff may apply if shipping to the United States related to import and export transactions. Maximum Vce(on) at Vge Tariff may apply if shipping to the United States for transistor specifications. Viewing angle 120° for monitors. Common forward voltage Vf 2.95V for diode operation.
