Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | OSLON® Square | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Obsolete | |
| Visual Hue | White, Warm | |
| Color Temperature Kelvin | 2700K | |
| Flux at 85C Test Current | 330lm (300lm ~ 360lm) | |
| Flux at 25C Test Current | - | |
| Testing Current Value | 700mA | |
| Typical Forward Voltage | 2.8V | |
| Efficiency Lumens per Watt | 168 lm/W | |
| Color Accuracy Rating | 70 | |
| Maximum Amp Rating | 1.8A | |
| Display View Cone Degrees | 120° | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 1212 (3030 Metric) | |
| Vendor Package Type | 1212 | |
| Package Size Specs | 0.118" L x 0.118" W (3.00mm x 3.00mm) | |
| Maximum Mounted Height | 0.085" (2.16mm) |
Description
Offers a correlated color temperature of 2700KK to create the desired lighting ambiance. Has a CRI score of 70 for accurate color depiction. Offered in a shade referred to as White, Warm to enhance the system's aesthetics. Indicates the maximum allowable current rating at 1.8A. Assessed at current levels outlined by 700mA. Reveals flux at 85°C measured at 330lm (300lm ~ 360lm). Maximum installed height of 0.085" (2.16mm) for components affixed to the board. Employs 2700K light type for maximum brightness. The lumens per watt 168 lm/W evaluated at the testing current to determine lighting efficiency. Mounting configuration Surface Mount for structural stability. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 1212 (3030 Metric) that offers mechanical and thermal protection. Type of package 1212 that preserves the integrity of the device. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component OSLON® Square. Details on package size 0.118" L x 0.118" W (3.00mm x 3.00mm) for electrical or mechanical components. Measurement dimensions 0.118" L x 0.118" W (3.00mm x 3.00mm) for component specifications. Supplier package type 1212 for component selection. Viewing angle 120° for monitors. Common forward voltage Vf 2.8V for diode operation.
