Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Obsolete | |
| Visual Hue | Red, Green, Blue (RGB) | |
| Setup Arrangement | Independent | |
| Optical Lens Tint | White | |
| Lens Clarity Level | Diffused | |
| LED Brightness mcd | 113mcd Red, 260.5mcd Green, 104mcd Blue | |
| Lens Shape Design | Rectangle with Flat Top | |
| Focal Lens Dimensions | 1.40mm x 2.40mm | |
| Typical Forward Voltage | 2V Red, 3.5V Green, 3.5V Blue | |
| Testing Current Value | 20mA Red, 20mA Green, 20mA Blue | |
| Display View Cone Degrees | 130° | |
| Attachment Mounting Style | Surface Mount | |
| Primary Emission Wavelength | 615nm Red, 525nm Green, 470nm Blue | |
| Peak Intensity Wavelength | 621nm Red, 520nm Green, 468nm Blue | |
| Key Product Highlights | - | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Component Housing Style | 4-SMD, No Lead | |
| Vendor Package Type | Chip LED | |
| Package Size Specs | 2.40mm L x 2.00mm W | |
| Upper Height Limit | 0.80mm |
Description
Offered in a shade referred to as Red, Green, Blue (RGB) to enhance the system's aesthetics. Configured in a manner identified as Independent. Assessed at current levels outlined by 20mA Red, 20mA Green, 20mA Blue. Maintains a maximum height of 0.80mm to comply with design standards. Lens color White for improved visual clarity or signaling. Lens dimensions 1.40mm x 2.40mm for proper fitting and application. Lens configuration Rectangle with Flat Top combining utility with aesthetic appeal. Lens transparency Diffused ensuring maximum light passage. Millicandela measurement 113mcd Red, 260.5mcd Green, 104mcd Blue for LED or light intensity. Mounting configuration Surface Mount for structural stability. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 4-SMD, No Lead that offers mechanical and thermal protection. Type of package Chip LED that preserves the integrity of the device. Product status Obsolete concerning availability and lifecycle. Details on package size 2.40mm L x 2.00mm W for electrical or mechanical components. Measurement dimensions 2.40mm L x 2.00mm W for component specifications. Supplier package type Chip LED for component selection. Viewing angle 130° for monitors. Common forward voltage Vf 2V Red, 3.5V Green, 3.5V Blue for diode operation. Primary wavelength of emission 615nm Red, 525nm Green, 470nm Blue for LEDs or optics. Wavelength at peak intensity 621nm Red, 520nm Green, 468nm Blue for optical devices.
