Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tube | |
| Availability Status | Obsolete | |
| Visual Hue | Red | |
| Setup Arrangement | Standard | |
| Optical Lens Tint | Colorless | |
| Lens Clarity Level | Clear | |
| LED Brightness mcd | 0.6mcd | |
| Lens Shape Design | Round with Domed Top | |
| Focal Lens Dimensions | 3.00mm Dia | |
| Typical Forward Voltage | 2.15V | |
| Testing Current Value | 70mA | |
| Display View Cone Degrees | 70° | |
| Attachment Mounting Style | Through Hole | |
| Primary Emission Wavelength | 618nm | |
| Peak Intensity Wavelength | 624nm | |
| Key Product Highlights | - | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Component Housing Style | 4-DIP (0.200", 5.08mm) | |
| Vendor Package Type | - | |
| Package Size Specs | 7.62mm L x 7.62mm W | |
| Upper Height Limit | 6.10mm |
Description
Offered in a shade referred to as Red to enhance the system's aesthetics. Configured in a manner identified as Standard. Assessed at current levels outlined by 70mA. Maintains a maximum height of 6.10mm to comply with design standards. Lens color Colorless for improved visual clarity or signaling. Lens dimensions 3.00mm Dia for proper fitting and application. Lens configuration Round with Domed Top combining utility with aesthetic appeal. Lens transparency Clear ensuring maximum light passage. Millicandela measurement 0.6mcd for LED or light intensity. Mounting configuration Through Hole for structural stability. Type of housing Tube for safeguarding or transporting components. Style of the enclosure/case 4-DIP (0.200", 5.08mm) that offers mechanical and thermal protection. Product status Obsolete concerning availability and lifecycle. Details on package size 7.62mm L x 7.62mm W for electrical or mechanical components. Measurement dimensions 7.62mm L x 7.62mm W for component specifications. Viewing angle 70° for monitors. Common forward voltage Vf 2.15V for diode operation. Primary wavelength of emission 618nm for LEDs or optics. Wavelength at peak intensity 624nm for optical devices.
