Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Obsolete | |
| Visual Hue | Blue | |
| Setup Arrangement | Standard | |
| Optical Lens Tint | Colorless | |
| Lens Clarity Level | Clear | |
| LED Brightness mcd | 20mcd | |
| Lens Shape Design | Rectangle with Flat Top | |
| Focal Lens Dimensions | 1.20mm x 0.80mm | |
| Typical Forward Voltage | 3.8V | |
| Testing Current Value | 20mA | |
| Display View Cone Degrees | 100° | |
| Attachment Mounting Style | Surface Mount | |
| Primary Emission Wavelength | 465nm | |
| Peak Intensity Wavelength | 430nm | |
| Key Product Highlights | - | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Component Housing Style | 0603 (1608 Metric) | |
| Vendor Package Type | - | |
| Package Size Specs | 1.60mm L x 0.80mm W | |
| Upper Height Limit | 0.80mm |
Description
Offered in a shade referred to as Blue to enhance the system's aesthetics. Configured in a manner identified as Standard. Assessed at current levels outlined by 20mA. Maintains a maximum height of 0.80mm to comply with design standards. Lens color Colorless for improved visual clarity or signaling. Lens dimensions 1.20mm x 0.80mm for proper fitting and application. Lens configuration Rectangle with Flat Top combining utility with aesthetic appeal. Lens transparency Clear ensuring maximum light passage. Millicandela measurement 20mcd for LED or light intensity. Mounting configuration Surface Mount for structural stability. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 0603 (1608 Metric) that offers mechanical and thermal protection. Product status Obsolete concerning availability and lifecycle. Details on package size 1.60mm L x 0.80mm W for electrical or mechanical components. Measurement dimensions 1.60mm L x 0.80mm W for component specifications. Viewing angle 100° for monitors. Common forward voltage Vf 3.8V for diode operation. Primary wavelength of emission 465nm for LEDs or optics. Wavelength at peak intensity 430nm for optical devices.
