Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | Micro SIDELED® 3010 | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Obsolete | |
| Visual Hue | Amber | |
| Setup Arrangement | Standard | |
| Optical Lens Tint | Colorless | |
| Lens Clarity Level | Clear | |
| LED Brightness mcd | 157mcd | |
| Lens Shape Design | Rectangle with Flat Top | |
| Focal Lens Dimensions | 1.70mm x 0.70mm | |
| Typical Forward Voltage | 2V | |
| Testing Current Value | 20mA | |
| Display View Cone Degrees | 120° | |
| Attachment Mounting Style | Surface Mount, Right Angle | |
| Primary Emission Wavelength | 615nm | |
| Peak Intensity Wavelength | 622nm | |
| Key Product Highlights | - | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Component Housing Style | 2-SMD, Flat Leads | |
| Vendor Package Type | SMD | |
| Package Size Specs | 2.20mm L x 1.20mm W | |
| Upper Height Limit | 1.20mm |
Description
Offered in a shade referred to as Amber to enhance the system's aesthetics. Configured in a manner identified as Standard. Assessed at current levels outlined by 20mA. Maintains a maximum height of 1.20mm to comply with design standards. Lens color Colorless for improved visual clarity or signaling. Lens dimensions 1.70mm x 0.70mm for proper fitting and application. Lens configuration Rectangle with Flat Top combining utility with aesthetic appeal. Lens transparency Clear ensuring maximum light passage. Millicandela measurement 157mcd for LED or light intensity. Mounting configuration Surface Mount, Right Angle for structural stability. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 2-SMD, Flat Leads that offers mechanical and thermal protection. Type of package SMD that preserves the integrity of the device. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component Micro SIDELED® 3010. Details on package size 2.20mm L x 1.20mm W for electrical or mechanical components. Measurement dimensions 2.20mm L x 1.20mm W for component specifications. Supplier package type SMD for component selection. Viewing angle 120° for monitors. Common forward voltage Vf 2V for diode operation. Primary wavelength of emission 615nm for LEDs or optics. Wavelength at peak intensity 622nm for optical devices.
