Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | DISPLIX® P3333 | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Obsolete | |
| Visual Hue | Red, Green, Blue (RGB) | |
| Setup Arrangement | Independent | |
| Optical Lens Tint | - | |
| Lens Clarity Level | Diffused | |
| LED Brightness mcd | 1025mcd Red, 2351mcd Green, 457.5mcd Blue | |
| Lens Shape Design | Rectangle with Flat Top | |
| Focal Lens Dimensions | 2.80mm x 2.60mm | |
| Typical Forward Voltage | 2.05V Red, 2.65V Green, 2.85V Blue | |
| Testing Current Value | 20mA Red, 20mA Green, 20mA Blue | |
| Display View Cone Degrees | 120° | |
| Attachment Mounting Style | Surface Mount | |
| Primary Emission Wavelength | 621nm Red, 532nm Green, 467nm Blue | |
| Peak Intensity Wavelength | 634nm Red, 526nm Green, 462nm Blue | |
| Key Product Highlights | - | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Component Housing Style | 6-SMD, J-Lead | |
| Vendor Package Type | 6-PLCC | |
| Package Size Specs | 3.30mm L x 3.10mm W | |
| Upper Height Limit | 2.24mm |
Description
Offered in a shade referred to as Red, Green, Blue (RGB) to enhance the system's aesthetics. Configured in a manner identified as Independent. Assessed at current levels outlined by 20mA Red, 20mA Green, 20mA Blue. Maintains a maximum height of 2.24mm to comply with design standards. Lens dimensions 2.80mm x 2.60mm for proper fitting and application. Lens configuration Rectangle with Flat Top combining utility with aesthetic appeal. Lens transparency Diffused ensuring maximum light passage. Millicandela measurement 1025mcd Red, 2351mcd Green, 457.5mcd Blue for LED or light intensity. Mounting configuration Surface Mount for structural stability. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 6-SMD, J-Lead that offers mechanical and thermal protection. Type of package 6-PLCC that preserves the integrity of the device. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component DISPLIX® P3333. Details on package size 3.30mm L x 3.10mm W for electrical or mechanical components. Measurement dimensions 3.30mm L x 3.10mm W for component specifications. Supplier package type 6-PLCC for component selection. Viewing angle 120° for monitors. Common forward voltage Vf 2.05V Red, 2.65V Green, 2.85V Blue for diode operation. Primary wavelength of emission 621nm Red, 532nm Green, 467nm Blue for LEDs or optics. Wavelength at peak intensity 634nm Red, 526nm Green, 462nm Blue for optical devices.
