Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | SMARTLED® 0603 | |
| IC Encapsulation Type | Tape & Reel (TR)Cut Tape (CT)Digi-Reel® | |
| Availability Status | Active | |
| Visual Hue | Orange | |
| Setup Arrangement | Standard | |
| Optical Lens Tint | Colorless | |
| Lens Clarity Level | Diffused | |
| LED Brightness mcd | 175.5mcd | |
| Lens Shape Design | Rectangle with Flat Top | |
| Focal Lens Dimensions | 1.16mm x 0.80mm | |
| Typical Forward Voltage | 2V | |
| Testing Current Value | 20mA | |
| Display View Cone Degrees | 130°, 130° | |
| Attachment Mounting Style | Surface Mount | |
| Primary Emission Wavelength | 605nm | |
| Peak Intensity Wavelength | 610nm | |
| Key Product Highlights | - | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Component Housing Style | 0603 (1608 Metric) | |
| Vendor Package Type | 0603 | |
| Package Size Specs | 1.60mm L x 0.80mm W | |
| Upper Height Limit | 0.50mm |
Description
Offered in a shade referred to as Orange to enhance the system's aesthetics. Configured in a manner identified as Standard. Assessed at current levels outlined by 20mA. Maintains a maximum height of 0.50mm to comply with design standards. Lens color Colorless for improved visual clarity or signaling. Lens dimensions 1.16mm x 0.80mm for proper fitting and application. Lens configuration Rectangle with Flat Top combining utility with aesthetic appeal. Lens transparency Diffused ensuring maximum light passage. Millicandela measurement 175.5mcd for LED or light intensity. Mounting configuration Surface Mount for structural stability. Type of housing Tape & Reel (TR)Cut Tape (CT)Digi-Reel® for safeguarding or transporting components. Style of the enclosure/case 0603 (1608 Metric) that offers mechanical and thermal protection. Type of package 0603 that preserves the integrity of the device. Product status Active concerning availability and lifecycle. Classification series for the product or component SMARTLED® 0603. Details on package size 1.60mm L x 0.80mm W for electrical or mechanical components. Measurement dimensions 1.60mm L x 0.80mm W for component specifications. Supplier package type 0603 for component selection. Viewing angle 130°, 130° for monitors. Common forward voltage Vf 2V for diode operation. Primary wavelength of emission 605nm for LEDs or optics. Wavelength at peak intensity 610nm for optical devices.
