Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | Optimal IV Star | |
| IC Encapsulation Type | Tube | |
| Availability Status | Obsolete | |
| Device Type Classification | LED Module | |
| Visual Hue | Red, Green, Blue, Amber (RGBA) | |
| Color Temperature Kelvin | - | |
| Light Wavelength nm | 625nm Red, 522nm Green, 455nm Blue, 585nm Amber | |
| Setup Arrangement | Starboard | |
| Lumens at Specified Amps/Temp | 35lm (Typ) Red, 30lm (Typ) Green, 5lm (Typ) Blue, 36lm (Typ) Amber | |
| Testing Current Value | 350mA Red, 350mA Green, 350mA Blue, 350mA Amber | |
| Testing Temperature Condition | 25°C | |
| Typical Forward Voltage | 2.5V Red, 3.9V Green, 3.6V Blue, 2.5V Amber | |
| Efficiency Lumens per Watt | 40 lm/W Red, 22 lm/W Green, 4 lm/W Blue, 41 lm/W Amber | |
| Maximum Amp Rating | 700mA Red, 700mA Green, 700mA Blue, 700mA Amber | |
| Color Accuracy Rating | - | |
| Display View Cone Degrees | 60° | |
| Key Product Highlights | - | |
| Package Size Specs | 21.00mm Dia | |
| Vertical Dimension | 5.00mm | |
| LED Light Output Area | - | |
| Optical Element Category | Domed |
Description
Offered in a shade referred to as Red, Green, Blue, Amber (RGBA) to enhance the system's aesthetics. Configured in a manner identified as Starboard. Indicates the maximum allowable current rating at 700mA Red, 700mA Green, 700mA Blue, 700mA Amber. Assessed at current levels outlined by 350mA Red, 350mA Green, 350mA Blue, 350mA Amber. Features a height of 5.00mm for accurate dimensional precision. Features Domed lens type tailored for specific application requirements. The lumens per watt 40 lm/W Red, 22 lm/W Green, 4 lm/W Blue, 41 lm/W Amber evaluated at the testing current to determine lighting efficiency. The luminous output 35lm (Typ) Red, 30lm (Typ) Green, 5lm (Typ) Blue, 36lm (Typ) Amber at specified current and temperature for reliable performance. Type of housing Tube for safeguarding or transporting components. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component Optimal IV Star. Details on package size 21.00mm Dia for electrical or mechanical components. Measurement dimensions 21.00mm Dia for component specifications. The temperature condition for testing 25°C aimed at qualification procedures. Type classification LED Module for specifications. Viewing angle 60° for monitors. Common forward voltage Vf 2.5V Red, 3.9V Green, 3.6V Blue, 2.5V Amber for diode operation. Wavelength of light 625nm Red, 522nm Green, 455nm Blue, 585nm Amber for RF or optical devices.
