Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | OSRAM OSTAR® Projection Power | |
| IC Encapsulation Type | Tray | |
| Availability Status | Obsolete | |
| Device Type Classification | LED Module | |
| Visual Hue | Blue | |
| Color Temperature Kelvin | - | |
| Light Wavelength nm | 440nm (435nm ~ 445nm) | |
| Setup Arrangement | Rectangle | |
| Lumens at Specified Amps/Temp | 17500mW (14000mW ~ 21000mW) | |
| Testing Current Value | 6A | |
| Testing Temperature Condition | 25°C | |
| Typical Forward Voltage | 7V | |
| Efficiency Lumens per Watt | - | |
| Maximum Amp Rating | 10A | |
| Color Accuracy Rating | - | |
| Display View Cone Degrees | 120° | |
| Key Product Highlights | With Connector | |
| Package Size Specs | 27.00mm L x 15.50mm W | |
| Vertical Dimension | 1.90mm | |
| LED Light Output Area | 8.20mm L x 1.55mm W | |
| Optical Element Category | Flat |
Description
Offered in a shade referred to as Blue to enhance the system's aesthetics. Configured in a manner identified as Rectangle. Indicates the maximum allowable current rating at 10A. Assessed at current levels outlined by 6A. Equipped with features categorized as With Connector. Features a height of 1.90mm for accurate dimensional precision. Features Flat lens type tailored for specific application requirements. Light output zone 8.20mm L x 1.55mm W for efficient lighting. The luminous output 17500mW (14000mW ~ 21000mW) at specified current and temperature for reliable performance. Type of housing Tray for safeguarding or transporting components. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component OSRAM OSTAR® Projection Power. Details on package size 27.00mm L x 15.50mm W for electrical or mechanical components. Measurement dimensions 27.00mm L x 15.50mm W for component specifications. The temperature condition for testing 25°C aimed at qualification procedures. Type classification LED Module for specifications. Viewing angle 120° for monitors. Common forward voltage Vf 7V for diode operation. Wavelength of light 440nm (435nm ~ 445nm) for RF or optical devices.
