Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tube | |
| Availability Status | Obsolete | |
| Screen Output Layout | - | |
| Display Character Capacity | 1 | |
| Package Size Specs | 0.394" H x 0.291" W x 0.240" D (10.00mm x 7.40mm x 6.10mm) | |
| Numeric/Alphabetic Font Size | 0.28" (7.00mm) | |
| Screen Technology Type | 7-Segment | |
| Shared Connection Point | Common Anode | |
| Visual Hue | Blue | |
| Typical Forward Voltage | 3.8V | |
| Testing Current Value | 20mA | |
| LED Brightness mcd | 3mcd | |
| Peak Intensity Wavelength | 428nm | |
| Max Heat Dissipation | 65mW | |
| Component Housing Style | 10-DIP (0.300", 7.62mm) |
Description
Offered in a shade referred to as Blue to enhance the system's aesthetics. Includes a shared pin marked as Common Anode for precise circuit identification. Assessed at current levels outlined by 20mA. Displays the size of digits or letters shown as 0.28" (7.00mm). Features a display type recognized as 7-Segment. Millicandela measurement 3mcd for LED or light intensity. Overall characters 1 for display or text representation. Type of housing Tube for safeguarding or transporting components. Style of the enclosure/case 10-DIP (0.300", 7.62mm) that offers mechanical and thermal protection. The maximum power dissipation 65mW for efficient thermal management. Product status Obsolete concerning availability and lifecycle. Details on package size 0.394" H x 0.291" W x 0.240" D (10.00mm x 7.40mm x 6.10mm) for electrical or mechanical components. Measurement dimensions 0.394" H x 0.291" W x 0.240" D (10.00mm x 7.40mm x 6.10mm) for component specifications. Common forward voltage Vf 3.8V for diode operation. Wavelength at peak intensity 428nm for optical devices.
