Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Screen Output Layout | - | |
| Display Character Capacity | 1 | |
| Package Size Specs | 1.398" H x 0.945" W x 0.343" D (35.50mm x 24.00mm x 8.70mm) | |
| Numeric/Alphabetic Font Size | 1.00" (25.40mm) | |
| Screen Technology Type | 7-Segment | |
| Shared Connection Point | Common Anode | |
| Visual Hue | Red, Green, Blue (RGB) | |
| Typical Forward Voltage | 2.1V Red, 3.5V Green, 3.4V Blue | |
| Testing Current Value | 20mA Red, 20mA Green, 20mA Blue | |
| LED Brightness mcd | 244mcd Red, 552mcd Green, 100mcd Blue | |
| Peak Intensity Wavelength | 616nm Red, 523nm Green, 468nm Blue | |
| Max Heat Dissipation | 150mW | |
| Component Housing Style | 25-DIP Module |
Description
Offered in a shade referred to as Red, Green, Blue (RGB) to enhance the system's aesthetics. Includes a shared pin marked as Common Anode for precise circuit identification. Assessed at current levels outlined by 20mA Red, 20mA Green, 20mA Blue. Displays the size of digits or letters shown as 1.00" (25.40mm). Features a display type recognized as 7-Segment. Millicandela measurement 244mcd Red, 552mcd Green, 100mcd Blue for LED or light intensity. Overall characters 1 for display or text representation. Type of housing Bulk for safeguarding or transporting components. Style of the enclosure/case 25-DIP Module that offers mechanical and thermal protection. The maximum power dissipation 150mW for efficient thermal management. Product status Obsolete concerning availability and lifecycle. Details on package size 1.398" H x 0.945" W x 0.343" D (35.50mm x 24.00mm x 8.70mm) for electrical or mechanical components. Measurement dimensions 1.398" H x 0.945" W x 0.343" D (35.50mm x 24.00mm x 8.70mm) for component specifications. Common forward voltage Vf 2.1V Red, 3.5V Green, 3.4V Blue for diode operation. Wavelength at peak intensity 616nm Red, 523nm Green, 468nm Blue for optical devices.
