Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 5000 | ₹ 139.35000 | ₹ 6,96,750.00 |
| 1000 | ₹ 139.53000 | ₹ 1,39,530.00 |
| 500 | ₹ 149.08000 | ₹ 74,540.00 |
| 300 | ₹ 156.62000 | ₹ 46,986.00 |
| 100 | ₹ 174.42000 | ₹ 17,442.00 |
| 50 | ₹ 186.87000 | ₹ 9,343.50 |
| 25 | ₹ 200.37000 | ₹ 5,009.25 |
| 10 | ₹ 220.01000 | ₹ 2,200.10 |
| 1 | ₹ 280.03000 | ₹ 280.03 |
Stock:
Distributor: 108
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 279.46000 | ₹ 279.46 |
| 10 | ₹ 219.83000 | ₹ 2,198.30 |
| 20 | ₹ 200.25000 | ₹ 4,005.00 |
| 50 | ₹ 174.44000 | ₹ 8,722.00 |
| 100 | ₹ 162.87000 | ₹ 16,287.00 |
| 200 | ₹ 155.75000 | ₹ 31,150.00 |
| 500 | ₹ 148.63000 | ₹ 74,315.00 |
| 1000 | ₹ 143.29000 | ₹ 1,43,290.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tray | |
| Availability Status | Active | |
| Core Technology Platform | Magnetic | |
| Device Type Classification | General Purpose | |
| Operational Hz Spectrum | 550 Hz ~ 10 kHz | |
| Self-Resonance Frequency | 550Hz | |
| AC Resistance Value | 8 Ohms | |
| Noise Efficiency in dBA | 92.00 | |
| Tested Efficiency Metrics | 100mm | |
| Efficiency Measurement Method | Sound Pressure Level (SPL) | |
| Nominal Power Rating | 750 mW | |
| Maximum Power Handling | 1 W | |
| Connection Port Placement | Top | |
| Physical Shape Form | Rectangular | |
| Speaker Cone Material | Polyester, Polyethylene Terephthalate (PET) | |
| Magnetic Element Composition | - | |
| Dust Water Resistance Rating | - | |
| Performance Rating Specs | - | |
| Circuit End Method | Spring Type | |
| Package Size Specs | 0.591" L x 0.433" W (15.00mm x 11.00mm) | |
| Maximum Mounted Height | 0.118" (3.00mm) |
Description
Includes efficiency metrics assessed at 100mm. Shows the type of efficiency identified as Sound Pressure Level (SPL). Records efficiency measured at 92.00 dBA. Features a 550Hz self-resonant frequency that enhances component efficiency. Offers a 550 Hz ~ 10 kHz frequency spectrum for broad-spectrum applications. Maximum installed height of 0.118" (3.00mm) for components affixed to the board. Configured with 8 Ohms impedance to maintain signal quality. Substance Polyester, Polyethylene Terephthalate (PET) for the sound or mechanical role of the cone. Type of housing Tray for safeguarding or transporting components. The Top position of the port for installation reference. Energy requirement 750 mW for device functionality. Maximum power capability 1 W for safeguarding the device. Designated power 750 mW to meet compliance standards. Product status Active concerning availability and lifecycle. Shape Rectangular for the part or device. Details on package size 0.591" L x 0.433" W (15.00mm x 11.00mm) for electrical or mechanical components. Measurement dimensions 0.591" L x 0.433" W (15.00mm x 11.00mm) for component specifications. The primary technology platform Magnetic linked to the product category. Termination method Spring Type for electrical or mechanical connections. Type classification General Purpose for specifications.
