Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | B59407 | |
| IC Encapsulation Type | Tape & Reel (TR)Cut Tape (CT)Digi-Reel® | |
| Availability Status | Active | |
| Device Type Classification | Ceramic | |
| Peak Voltage Tolerance | 32V | |
| Maximum Holding Current | 13 mA | |
| Trip Threshold Current | 32 mA | |
| Maximum Amp Rating | 120 mA | |
| Fault Trip Duration | - | |
| Minimum Initial Resistance | 265 Ohms | |
| Max Post-Trip Resistance | 470 Ohms | |
| Typical Resistance at 25C | - | |
| Ambient Temp Range | -40°C ~ 125°C | |
| Quality Grade Level | Automotive | |
| Certification Qualification | AEC-Q200 | |
| Performance Rating Specs | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 0402 (1005 Metric) | |
| Package Size Specs | 0.039" L x 0.020" W (1.00mm x 0.50mm) | |
| Maximum Mounted Height | - | |
| Maximum Thickness Limit | 0.022" (0.55mm) | |
| Pin Lead Gap | - |
Description
Indicates the maximum holding current recorded at 13 mA. Indicates the maximum allowable current rating at 120 mA. Delivers trip current recorded at 32 mA. Evaluated as Automotive grade for quality control. Mounting configuration Surface Mount for structural stability. Temperature range -40°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR)Cut Tape (CT)Digi-Reel® for safeguarding or transporting components. Style of the enclosure/case 0402 (1005 Metric) that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Certification AEC-Q200 for compliance with testing or regulatory standards. The baseline initial resistance (Ri) 265 Ohms established for evaluating performance. The highest post-trip resistance (R1) 470 Ohms designed to safeguard the circuit. Classification series for the product or component B59407. Details on package size 0.039" L x 0.020" W (1.00mm x 0.50mm) for electrical or mechanical components. Measurement dimensions 0.039" L x 0.020" W (1.00mm x 0.50mm) for component specifications. The highest permissible thickness 0.022" (0.55mm) according to specification standards. Type classification Ceramic for specifications. The maximum voltage 32V specified by the device.
