Description

Indicates the maximum holding current recorded at 80 mA. Indicates the maximum allowable current rating at 40 A. Delivers trip current recorded at 200 mA. Evaluated as Automotive grade for quality control. Mounting configuration Surface Mount for structural stability. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 0603 (1608 Metric), Concave that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Certification AEC-Q200 for compliance with testing or regulatory standards. The baseline initial resistance (Ri) 2.8 Ohms established for evaluating performance. The highest post-trip resistance (R1) 14 Ohms designed to safeguard the circuit. Classification series for the product or component 0ZCM. Details on package size 0.063" L x 0.029" W (1.60mm x 0.73mm) for electrical or mechanical components. Measurement dimensions 0.063" L x 0.029" W (1.60mm x 0.73mm) for component specifications. The highest permissible thickness 0.024" (0.60mm) according to specification standards. Time required to trip 100 ms for safety systems. Type classification Polymeric for specifications. The maximum voltage 15V specified by the device.
