Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | E | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Active | |
| Peak AC Voltage Rating | 17 V | |
| Peak DC Voltage Limit | 22 V | |
| Min Clamp Voltage | 24.65 V | |
| Typical Varistor Voltage | 29 V | |
| Max Clamp Voltage | 33.35 V | |
| Surge Current Tolerance | 30 A | |
| Stored Energy Capacity | 0.1J | |
| Electrical Circuit Count | 1 | |
| Capacitance at Specific Hz | 100 pF @ 1 kHz | |
| Ambient Temp Range | -55°C ~ 150°C (TA) | |
| Key Product Highlights | - | |
| Quality Grade Level | Automotive | |
| Certification Qualification | AEC-Q200 | |
| Attachment Mounting Style | Surface Mount, MLCV | |
| Component Housing Style | 0805 (2012 Metric) |
Description
Delivers capacitance at a specified frequency of 100 pF @ 1 kHz. Is capable of withstanding surge current levels marked at 30 A. Represents the energy capacity noted at 0.1J. Evaluated as Automotive grade for quality control. Maximum signal delay 33.35 V at voltage for applications sensitive to timing. Maximum AC voltage 17 V for safe operation. Maximum DC voltage 22 V for safe electronic circuits. Mounting configuration Surface Mount, MLCV for structural stability. The total number of circuits stands at 1 for electrical or electronic setups. Temperature range -55°C ~ 150°C (TA) for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 0805 (2012 Metric) that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Certification AEC-Q200 for compliance with testing or regulatory standards. Classification series for the product or component E. Maximum varistor voltage 33.35 V for device protection. Minimum varistor voltage 24.65 V for device protection. Standard varistor voltage 29 V employed for circuit protection.
