Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 25000 | ₹ 23.16000 | ₹ 5,79,000.00 |
| 15000 | ₹ 23.20000 | ₹ 3,48,000.00 |
| 10000 | ₹ 24.01000 | ₹ 2,40,100.00 |
| 5000 | ₹ 25.46000 | ₹ 1,27,300.00 |
| 2500 | ₹ 28.35000 | ₹ 70,875.00 |
| 2500 | ₹ 28.35000 | ₹ 70,875.00 |
| 1000 | ₹ 29.18000 | ₹ 29,180.00 |
| 1000 | ₹ 29.18000 | ₹ 29,180.00 |
| 500 | ₹ 30.94000 | ₹ 15,470.00 |
| 500 | ₹ 30.94000 | ₹ 15,470.00 |
| 250 | ₹ 32.82000 | ₹ 8,205.00 |
| 250 | ₹ 32.82000 | ₹ 8,205.00 |
| 100 | ₹ 35.48000 | ₹ 3,548.00 |
| 100 | ₹ 35.48000 | ₹ 3,548.00 |
| 50 | ₹ 37.64000 | ₹ 1,882.00 |
| 50 | ₹ 37.64000 | ₹ 1,882.00 |
| 25 | ₹ 39.91000 | ₹ 997.75 |
| 25 | ₹ 39.91000 | ₹ 997.75 |
| 10 | ₹ 43.13000 | ₹ 431.30 |
| 10 | ₹ 43.13000 | ₹ 431.30 |
| 1 | ₹ 52.28000 | ₹ 52.28 |
| 1 | ₹ 52.28000 | ₹ 52.28 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | S2F | |
| IC Encapsulation Type | Tape & Reel (TR)Cut Tape (CT)- | |
| Availability Status | Active | |
| Attachment Mounting Style | Surface Mount | |
| Overcurrent Protection Style | Board Mount (Cartridge Style Excluded) | |
| Ampere Capacity Rating | 500 mA | |
| AC Voltage Max | - | |
| DC Voltage Max | 63 V | |
| Activation Speed ms | Fast Blow | |
| Component Housing Style | 1206 (3216 Metric) | |
| Interrupt Rating at Voltage | 50A | |
| Thermal Melting Integral | 0.011 | |
| Certification Body | UL | |
| Ambient Temp Range | -25°C ~ 125°C | |
| Visual Hue | - | |
| Package Size Specs | 0.122" L x 0.061" W x 0.024" H (3.10mm x 1.55mm x 0.60mm) |
Description
Complies with the criteria of entities acknowledged as UL. Has a breaking capacity of 50A at its designated voltage. Sets the ampere rating to 500 mA. Supports Board Mount (Cartridge Style Excluded) fuse specifications to meet safety standards. Melting I²t 0.011 for fuse or thermal protection. Mounting configuration Surface Mount for structural stability. Temperature range -25°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR)Cut Tape (CT)- for safeguarding or transporting components. Style of the enclosure/case 1206 (3216 Metric) that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Time taken to respond Fast Blow for rapid operation or detection. Classification series for the product or component S2F. Details on package size 0.122" L x 0.061" W x 0.024" H (3.10mm x 1.55mm x 0.60mm) for electrical or mechanical components. Measurement dimensions 0.122" L x 0.061" W x 0.024" H (3.10mm x 1.55mm x 0.60mm) for component specifications. The highest DC voltage specification 63 V for components.
