Stock:
Distributor: 113
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 4,165.50000 | ₹ 4,165.50 |
| 5 | ₹ 3,798.68000 | ₹ 18,993.40 |
| 10 | ₹ 3,741.61000 | ₹ 37,416.10 |
| 25 | ₹ 3,541.63000 | ₹ 88,540.75 |
| 50 | ₹ 3,404.57000 | ₹ 1,70,228.50 |
| 100 | ₹ 3,353.48000 | ₹ 3,35,348.00 |
| 250 | ₹ 3,238.60000 | ₹ 8,09,650.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | 7000 | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Attachment Mounting Style | Through Hole | |
| Inductor Operating Volts | 5VDC | |
| Switch Contact Layout | SPST-NO (1 Form A) | |
| Pin Ampere Capacity | 1 A | |
| Switch Rated Volts | 500VAC, 500VDC - Max | |
| Electromagnet Amp Draw | 71.4 mA | |
| Electromagnetic Coil Design | Non Latching | |
| Key Product Highlights | - | |
| Lead Termination Type | PC Pin | |
| Sealing Protection Grade | - | |
| Minimum Activation Volts | 3.75 VDC | |
| Release Voltage Level | 0.4 VDC | |
| Activation Response Time | 2 ms | |
| Reset Response Duration | 1 ms | |
| Ambient Temp Range | -20°C ~ 85°C | |
| Pin Alloy Composition | - |
Description
Supports coil current measured at 71.4 mA. Designed with a coil type classified as Non Latching for optimal electrical efficiency. Operates with a coil voltage of 5VDC for reliable functionality. Utilizes a contact configuration categorized as SPST-NO (1 Form A). Supports a contact current rating of 1 A. Mounting configuration Through Hole for structural stability. Needs a voltage of 3.75 VDC for effective activation. Requires a release voltage of 0.4 VDC for reliable functioning. Time duration 2 ms for the response upon activation. Temperature range -20°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Product status Obsolete concerning availability and lifecycle. Duration required 1 ms for reset and reaction. Classification series for the product or component 7000. The switch's voltage specification 500VAC, 500VDC - Max as per electrical regulations. Type of termination PC Pin for connector or device.
