Stock:
Distributor: 108
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 3360 | ₹ 137.95000 | ₹ 4,63,512.00 |
| 5005 | ₹ 134.39000 | ₹ 6,72,621.95 |
Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 3360 | ₹ 148.61000 | ₹ 4,99,329.60 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | EE2 | |
| IC Encapsulation Type | Tube | |
| Availability Status | Active | |
| Attachment Mounting Style | Surface Mount | |
| Inductor Operating Volts | 3VDC | |
| Switch Contact Layout | DPDT (2 Form C) | |
| Pin Ampere Capacity | 2 A | |
| Switch Rated Volts | 250VAC, 220VDC - Max | |
| Maximum Switch Load | 500VA, 440W | |
| Electromagnet Amp Draw | 33.3 mA | |
| Electromagnetic Coil Design | Latching, Single Coil | |
| Key Product Highlights | - | |
| Lead Termination Type | Gull Wing | |
| Sealing Protection Grade | - | |
| Wire Coil Cover | - | |
| Minimum Activation Volts | 2.25 VDC | |
| Release Voltage Level | - | |
| Activation Response Time | 2 ms | |
| Reset Response Duration | 1 ms | |
| Ambient Temp Range | -40°C ~ 85°C | |
| Pin Alloy Composition | Silver Alloy, Gold Alloy | |
| Certification Body | CSA, TUV, UL | |
| Electromechanical Relay Style | General Purpose | |
| Quality Grade Level | - | |
| Certification Qualification | - |
Description
Complies with the criteria of entities acknowledged as CSA, TUV, UL. Supports coil current measured at 33.3 mA. Designed with a coil type classified as Latching, Single Coil for optimal electrical efficiency. Operates with a coil voltage of 3VDC for reliable functionality. Utilizes a contact configuration categorized as DPDT (2 Form C). Constructed from the contact material known as Silver Alloy, Gold Alloy. Supports a contact current rating of 2 A. The maximum switching load 500VA, 440W for enhanced circuit performance. Mounting configuration Surface Mount for structural stability. Needs a voltage of 2.25 VDC for effective activation. Time duration 2 ms for the response upon activation. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Tube for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Configuration of relay General Purpose for controlling electrical circuits. Duration required 1 ms for reset and reaction. Classification series for the product or component EE2. The switch's voltage specification 250VAC, 220VDC - Max as per electrical regulations. Type of termination Gull Wing for connector or device.
