Description

Complies with the criteria of entities acknowledged as UR, VDE. Supports coil current measured at 28.1 mA. Designed with a coil type classified as Non Latching for optimal electrical efficiency. Operates with a coil voltage of 5VDC for reliable functionality. Utilizes a contact configuration categorized as DPDT (2 Form C). Constructed from the contact material known as Silver Nickel (AgNi), Gold (Au). Supports a contact current rating of 5 A. The maximum switching load 62.5VA, 60W for enhanced circuit performance. Mounting configuration Through Hole for structural stability. Needs a voltage of 3.75 VDC for effective activation. Requires a release voltage of 0.5 VDC for reliable functioning. Time duration 3 ms for the response upon activation. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Configuration of relay Telecom for controlling electrical circuits. Duration required 3 ms for reset and reaction. Ingress protection level Sealed - Hermetically for sealing. Classification series for the product or component IM, AXICOM. The switch's voltage specification 250VAC, 220VDC - Max as per electrical regulations. Type of termination PC Pin for connector or device.
