Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | IM, AXICOM | |
| IC Encapsulation Type | Tape & Reel (TR)Cut Tape (CT) | |
| Availability Status | Active | |
| Attachment Mounting Style | Surface Mount | |
| Inductor Operating Volts | 4.5VDC | |
| Switch Contact Layout | DPDT (2 Form C) | |
| Pin Ampere Capacity | 5 A | |
| Switch Rated Volts | 250VAC, 220VDC - Max | |
| Maximum Switch Load | 62.5VA, 60W | |
| Electromagnet Amp Draw | 31.1 mA | |
| Electromagnetic Coil Design | Non Latching | |
| Key Product Highlights | - | |
| Lead Termination Type | Gull Wing | |
| Sealing Protection Grade | Sealed - Hermetically | |
| Wire Coil Cover | - | |
| Minimum Activation Volts | 3.38 VDC | |
| Release Voltage Level | 0.45 VDC | |
| Activation Response Time | 3 ms | |
| Reset Response Duration | 3 ms | |
| Ambient Temp Range | -40°C ~ 85°C | |
| Pin Alloy Composition | Silver Nickel (AgNi), Gold (Au) | |
| Certification Body | UR, VDE | |
| Electromechanical Relay Style | Telecom | |
| Quality Grade Level | - | |
| Certification Qualification | - |
Description
Complies with the criteria of entities acknowledged as UR, VDE. Supports coil current measured at 31.1 mA. Designed with a coil type classified as Non Latching for optimal electrical efficiency. Operates with a coil voltage of 4.5VDC for reliable functionality. Utilizes a contact configuration categorized as DPDT (2 Form C). Constructed from the contact material known as Silver Nickel (AgNi), Gold (Au). Supports a contact current rating of 5 A. The maximum switching load 62.5VA, 60W for enhanced circuit performance. Mounting configuration Surface Mount for structural stability. Needs a voltage of 3.38 VDC for effective activation. Requires a release voltage of 0.45 VDC for reliable functioning. Time duration 3 ms for the response upon activation. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR)Cut Tape (CT) for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Configuration of relay Telecom for controlling electrical circuits. Duration required 3 ms for reset and reaction. Ingress protection level Sealed - Hermetically for sealing. Classification series for the product or component IM, AXICOM. The switch's voltage specification 250VAC, 220VDC - Max as per electrical regulations. Type of termination Gull Wing for connector or device.
