Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | RAST 5, SCHRACK | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Attachment Mounting Style | Chassis Mount | |
| Inductor Operating Volts | 12VDC | |
| Switch Contact Layout | DPST-NO (2 Form A) | |
| Pin Ampere Capacity | 16 A | |
| Switch Rated Volts | 400VAC - Max | |
| Maximum Switch Load | 6400VA | |
| Electromagnet Amp Draw | 60 mA | |
| Electromagnetic Coil Design | Non Latching | |
| Key Product Highlights | - | |
| Lead Termination Type | Connector | |
| Sealing Protection Grade | - | |
| Wire Coil Cover | - | |
| Minimum Activation Volts | 7.5 VDC | |
| Release Voltage Level | 0.9 VDC | |
| Activation Response Time | - | |
| Reset Response Duration | - | |
| Ambient Temp Range | -20°C ~ 85°C | |
| Pin Alloy Composition | Silver Copper (AgCu3) | |
| Certification Body | cURus, VDE | |
| Electromechanical Relay Style | General Purpose | |
| Quality Grade Level | - | |
| Certification Qualification | - |
Description
Complies with the criteria of entities acknowledged as cURus, VDE. Supports coil current measured at 60 mA. Designed with a coil type classified as Non Latching for optimal electrical efficiency. Operates with a coil voltage of 12VDC for reliable functionality. Utilizes a contact configuration categorized as DPST-NO (2 Form A). Constructed from the contact material known as Silver Copper (AgCu3). Supports a contact current rating of 16 A. The maximum switching load 6400VA for enhanced circuit performance. Mounting configuration Chassis Mount for structural stability. Needs a voltage of 7.5 VDC for effective activation. Requires a release voltage of 0.9 VDC for reliable functioning. Temperature range -20°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Product status Obsolete concerning availability and lifecycle. Configuration of relay General Purpose for controlling electrical circuits. Classification series for the product or component RAST 5, SCHRACK. The switch's voltage specification 400VAC - Max as per electrical regulations. Type of termination Connector for connector or device.
