Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | RT-3 | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Attachment Mounting Style | DIN Rail | |
| Inductor Operating Volts | 24VDC | |
| Switch Contact Layout | SPST-NO (1 Form A) x 4 | |
| Pin Ampere Capacity | 3 A | |
| Switch Rated Volts | 250VAC, 30VDC - Max | |
| Maximum Switch Load | 750VA, 90W | |
| Electromagnet Amp Draw | 7.5 mA | |
| Electromagnetic Coil Design | Non Latching | |
| Key Product Highlights | Lighted Indicator, Socket Included | |
| Lead Termination Type | Screw Terminal | |
| Sealing Protection Grade | - | |
| Wire Coil Cover | - | |
| Minimum Activation Volts | 16.8 VDC | |
| Release Voltage Level | 1.2 VDC | |
| Activation Response Time | - | |
| Reset Response Duration | - | |
| Ambient Temp Range | -20°C ~ 55°C | |
| Pin Alloy Composition | - | |
| Certification Body | - | |
| Electromechanical Relay Style | General Purpose | |
| Quality Grade Level | - | |
| Certification Qualification | - |
Description
Supports coil current measured at 7.5 mA. Designed with a coil type classified as Non Latching for optimal electrical efficiency. Operates with a coil voltage of 24VDC for reliable functionality. Utilizes a contact configuration categorized as SPST-NO (1 Form A) x 4. Supports a contact current rating of 3 A. Equipped with features categorized as Lighted Indicator, Socket Included. The maximum switching load 750VA, 90W for enhanced circuit performance. Mounting configuration DIN Rail for structural stability. Needs a voltage of 16.8 VDC for effective activation. Requires a release voltage of 1.2 VDC for reliable functioning. Temperature range -20°C ~ 55°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Product status Obsolete concerning availability and lifecycle. Configuration of relay General Purpose for controlling electrical circuits. Classification series for the product or component RT-3. The switch's voltage specification 250VAC, 30VDC - Max as per electrical regulations. Type of termination Screw Terminal for connector or device.
