Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | JV-N | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Attachment Mounting Style | Through Hole | |
| Inductor Operating Volts | 12VDC | |
| Switch Contact Layout | SPST-NO (1 Form A) | |
| Pin Ampere Capacity | 16 A | |
| Switch Rated Volts | 277VAC, 30VDC - Max | |
| Maximum Switch Load | 4432VA, 480W | |
| Electromagnet Amp Draw | 16.7 mA | |
| Electromagnetic Coil Design | Non Latching | |
| Key Product Highlights | - | |
| Lead Termination Type | PC Pin | |
| Sealing Protection Grade | Sealed - Fully | |
| Wire Coil Cover | - | |
| Minimum Activation Volts | 9 VDC | |
| Release Voltage Level | 0.6 VDC | |
| Activation Response Time | 12 ms | |
| Reset Response Duration | 5 ms | |
| Ambient Temp Range | -40°C ~ 70°C | |
| Pin Alloy Composition | Silver Tin Oxide (AgSnO) | |
| Certification Body | CSA, UR, VDE | |
| Electromechanical Relay Style | General Purpose | |
| Quality Grade Level | - | |
| Certification Qualification | - |
Description
Complies with the criteria of entities acknowledged as CSA, UR, VDE. Supports coil current measured at 16.7 mA. Designed with a coil type classified as Non Latching for optimal electrical efficiency. Operates with a coil voltage of 12VDC for reliable functionality. Utilizes a contact configuration categorized as SPST-NO (1 Form A). Constructed from the contact material known as Silver Tin Oxide (AgSnO). Supports a contact current rating of 16 A. The maximum switching load 4432VA, 480W for enhanced circuit performance. Mounting configuration Through Hole for structural stability. Needs a voltage of 9 VDC for effective activation. Requires a release voltage of 0.6 VDC for reliable functioning. Time duration 12 ms for the response upon activation. Temperature range -40°C ~ 70°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Configuration of relay General Purpose for controlling electrical circuits. Duration required 5 ms for reset and reaction. Ingress protection level Sealed - Fully for sealing. Classification series for the product or component JV-N. The switch's voltage specification 277VAC, 30VDC - Max as per electrical regulations. Type of termination PC Pin for connector or device.
