Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Box | |
| Availability Status | Active | |
| Attachment Mounting Style | DIN Rail | |
| Inductor Operating Volts | 24VAC/DC | |
| Switch Contact Layout | SPDT (1 Form C) | |
| Pin Ampere Capacity | 6 A | |
| Switch Rated Volts | 250VAC, 250VDC - Max | |
| Maximum Switch Load | 1500VA, 120W | |
| Electromagnet Amp Draw | 17 mA | |
| Electromagnetic Coil Design | Non Latching | |
| Key Product Highlights | - | |
| Lead Termination Type | Screw Terminal | |
| Sealing Protection Grade | - | |
| Wire Coil Cover | - | |
| Minimum Activation Volts | 19.2 VAC/DC | |
| Release Voltage Level | - | |
| Activation Response Time | 15 ms | |
| Reset Response Duration | 10 ms | |
| Ambient Temp Range | -25°C ~ 60°C | |
| Pin Alloy Composition | Silver Tin Oxide (AgSnO) | |
| Certification Body | CCC, cCSAus, CE, cURus, UKCA | |
| Electromechanical Relay Style | General Purpose | |
| Quality Grade Level | - | |
| Certification Qualification | - |
Description
Complies with the criteria of entities acknowledged as CCC, cCSAus, CE, cURus, UKCA. Supports coil current measured at 17 mA. Designed with a coil type classified as Non Latching for optimal electrical efficiency. Operates with a coil voltage of 24VAC/DC for reliable functionality. Utilizes a contact configuration categorized as SPDT (1 Form C). Constructed from the contact material known as Silver Tin Oxide (AgSnO). Supports a contact current rating of 6 A. The maximum switching load 1500VA, 120W for enhanced circuit performance. Mounting configuration DIN Rail for structural stability. Needs a voltage of 19.2 VAC/DC for effective activation. Time duration 15 ms for the response upon activation. Temperature range -25°C ~ 60°C for environmental conditions impacting thermal efficiency. Type of housing Box for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Configuration of relay General Purpose for controlling electrical circuits. Duration required 10 ms for reset and reaction. The switch's voltage specification 250VAC, 250VDC - Max as per electrical regulations. Type of termination Screw Terminal for connector or device.
