Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | HD | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Attachment Mounting Style | Chassis Mount | |
| Inductor Operating Volts | 24VDC | |
| Switch Contact Layout | SPDT (1 Form C) | |
| Pin Ampere Capacity | 300 A | |
| Switch Rated Volts | 32VDC - Max | |
| Maximum Switch Load | 9600W | |
| Electromagnet Amp Draw | - | |
| Electromagnetic Coil Design | Latching, Single Coil | |
| Key Product Highlights | Lighted Indicator, Test Button | |
| Lead Termination Type | Screw Terminal | |
| Sealing Protection Grade | Sealed - Fully | |
| Wire Coil Cover | - | |
| Minimum Activation Volts | - | |
| Release Voltage Level | - | |
| Activation Response Time | - | |
| Reset Response Duration | - | |
| Ambient Temp Range | -50°C ~ 85°C | |
| Pin Alloy Composition | Silver Alloy | |
| Certification Body | - | |
| Electromechanical Relay Style | General Purpose | |
| Quality Grade Level | - | |
| Certification Qualification | - |
Description
Designed with a coil type classified as Latching, Single Coil for optimal electrical efficiency. Operates with a coil voltage of 24VDC for reliable functionality. Utilizes a contact configuration categorized as SPDT (1 Form C). Constructed from the contact material known as Silver Alloy. Supports a contact current rating of 300 A. Equipped with features categorized as Lighted Indicator, Test Button. The maximum switching load 9600W for enhanced circuit performance. Mounting configuration Chassis Mount for structural stability. Temperature range -50°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Configuration of relay General Purpose for controlling electrical circuits. Ingress protection level Sealed - Fully for sealing. Classification series for the product or component HD. The switch's voltage specification 32VDC - Max as per electrical regulations. Type of termination Screw Terminal for connector or device.
