Stock:
Distributor: 108
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 10 | ₹ 13,196.92000 | ₹ 1,31,969.20 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | JR | |
| IC Encapsulation Type | BulkBox | |
| Availability Status | Obsolete | |
| Attachment Mounting Style | Socketable | |
| Inductor Operating Volts | 110VAC | |
| Switch Contact Layout | DPDT (2 Form C) | |
| Pin Ampere Capacity | 10 A | |
| Switch Rated Volts | 250VAC, 250VDC - Max | |
| Maximum Switch Load | 2200VA, 80W | |
| Electromagnet Amp Draw | - | |
| Electromagnetic Coil Design | Latching, Single Coil | |
| Key Product Highlights | Lighted Indicator | |
| Lead Termination Type | Plug In, 11 Pin (Octal) | |
| Sealing Protection Grade | - | |
| Wire Coil Cover | - | |
| Minimum Activation Volts | - | |
| Release Voltage Level | - | |
| Activation Response Time | - | |
| Reset Response Duration | - | |
| Ambient Temp Range | -10°C ~ 60°C | |
| Pin Alloy Composition | Silver Cadmium Oxide (AgCdO) | |
| Certification Body | CSA, UL | |
| Electromechanical Relay Style | Impulse | |
| Quality Grade Level | - | |
| Certification Qualification | - |
Description
Complies with the criteria of entities acknowledged as CSA, UL. Designed with a coil type classified as Latching, Single Coil for optimal electrical efficiency. Operates with a coil voltage of 110VAC for reliable functionality. Utilizes a contact configuration categorized as DPDT (2 Form C). Constructed from the contact material known as Silver Cadmium Oxide (AgCdO). Supports a contact current rating of 10 A. Equipped with features categorized as Lighted Indicator. The maximum switching load 2200VA, 80W for enhanced circuit performance. Mounting configuration Socketable for structural stability. Temperature range -10°C ~ 60°C for environmental conditions impacting thermal efficiency. Type of housing BulkBox for safeguarding or transporting components. Product status Obsolete concerning availability and lifecycle. Configuration of relay Impulse for controlling electrical circuits. Classification series for the product or component JR. The switch's voltage specification 250VAC, 250VDC - Max as per electrical regulations. Type of termination Plug In, 11 Pin (Octal) for connector or device.
