Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Attachment Mounting Style | Chassis Mount | |
| Inductor Operating Volts | 24VDC | |
| Switch Contact Layout | SPST-NO (1 Form A) | |
| Pin Ampere Capacity | 100 A | |
| Switch Rated Volts | - | |
| Maximum Switch Load | - | |
| Electromagnet Amp Draw | 315.8 mA | |
| Electromagnetic Coil Design | Non Latching | |
| Key Product Highlights | - | |
| Lead Termination Type | Screw Terminal | |
| Sealing Protection Grade | - | |
| Wire Coil Cover | - | |
| Minimum Activation Volts | - | |
| Release Voltage Level | - | |
| Activation Response Time | 5 ms | |
| Reset Response Duration | 5 ms | |
| Ambient Temp Range | -40°C ~ 60°C | |
| Pin Alloy Composition | Silver (Ag) | |
| Certification Body | - | |
| Electromechanical Relay Style | General Purpose | |
| Quality Grade Level | - | |
| Certification Qualification | - |
Description
Supports coil current measured at 315.8 mA. Designed with a coil type classified as Non Latching for optimal electrical efficiency. Operates with a coil voltage of 24VDC for reliable functionality. Utilizes a contact configuration categorized as SPST-NO (1 Form A). Constructed from the contact material known as Silver (Ag). Supports a contact current rating of 100 A. Mounting configuration Chassis Mount for structural stability. Time duration 5 ms for the response upon activation. Temperature range -40°C ~ 60°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Configuration of relay General Purpose for controlling electrical circuits. Duration required 5 ms for reset and reaction. Type of termination Screw Terminal for connector or device.
