Attribute
Description
Manufacturer Part Number
24401-01
Manufacturer
Description
RELAY GEN PURPOSE DPST 85A 12V
Manufacturer Lead Time
--
Note :
GST will not be applied to orders shipping outside of India
Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 120 | ₹ 3,525.36000 | ₹ 4,23,043.20 |
| 80 | ₹ 3,623.27000 | ₹ 2,89,861.60 |
| 40 | ₹ 3,933.30000 | ₹ 1,57,332.00 |
| 5 | ₹ 5,018.32000 | ₹ 25,091.60 |
| 1 | ₹ 6,049.44000 | ₹ 6,049.44 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Attachment Mounting Style | Chassis Mount | |
| Inductor Operating Volts | 12VDC | |
| Switch Contact Layout | DPST-NO (2 Form A) | |
| Pin Ampere Capacity | 85 A | |
| Switch Rated Volts | - | |
| Maximum Switch Load | - | |
| Electromagnet Amp Draw | 685.7 mA | |
| Electromagnetic Coil Design | Non Latching | |
| Key Product Highlights | - | |
| Lead Termination Type | Screw Terminal | |
| Sealing Protection Grade | - | |
| Wire Coil Cover | - | |
| Minimum Activation Volts | - | |
| Release Voltage Level | - | |
| Activation Response Time | - | |
| Reset Response Duration | - | |
| Ambient Temp Range | - | |
| Pin Alloy Composition | Copper | |
| Certification Body | - | |
| Electromechanical Relay Style | General Purpose | |
| Quality Grade Level | - | |
| Certification Qualification | - |
Description
Supports coil current measured at 685.7 mA. Designed with a coil type classified as Non Latching for optimal electrical efficiency. Operates with a coil voltage of 12VDC for reliable functionality. Utilizes a contact configuration categorized as DPST-NO (2 Form A). Constructed from the contact material known as Copper. Supports a contact current rating of 85 A. Mounting configuration Chassis Mount for structural stability. Type of housing Bulk for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Configuration of relay General Purpose for controlling electrical circuits. Type of termination Screw Terminal for connector or device.
